Nikon Eclipse 80i Upright Microscope – Phase Contrast with Nikon Plan 10X/0.25 Ph1 DL & 40X/0.65 Ph2 DL  Objectives



 The Nikon Eclipse 80i is a high-performance upright research microscope engineered for advanced imaging applications. This configuration is optimized for phase contrast microscopy and includes precision Nikon CFI optics, a phase contrast condenser with turret, and Köhler illumination with field diaphragm for maximum contrast and resolution when imaging of stained, unstained or live specimens. Fully tested for beautiful imaging of IHC stained slides.



  Configuration & Specifications:








    Stand:

   Nikon Eclipse 80i upright microscope frame







    Eyepieces:

   Pair of Nikon 10X widefield eyepieces (total magnification up to 400X with included objectives)







    Condenser:

   Phase Contrast 0.90 Dry Condenser with

    6-position turret (wheel)








     Positions:

      Brightfield (BF), Phase 1 (Ph1), Phase 2 (Ph2), Phase 3 (Ph3), Darkfield (DF), Center (C)










    Objectives:








     Nikon CFI Plan 10X/0.25 Phase Contrast






     Nikon CFI Plan 40X/0.65







      Filters:












        ND8 Neutral Density Filter








        ND32 Neutral Density Filter








        NCB11 Blue Correction Filter

       (color balancing for halogen illumination)











    Magnification Range (with 10X eyepieces):


    100X (10X objective) to 400X (40X objective)








    Optical System:

   Nikon CFI60 infinity-corrected optics providing long working distances and superior resolution







    Illumination:

   Köhler illumination with adjustable

    field diaphragm

   and aperture diaphragm for precise light control







    Stage:

   Mechanical XY stage with manual stage controller for smooth, accurate specimen navigation







    Observation Modes:

   Brightfield, Phase Contrast (Ph1, Ph2, Ph3), Darkfield (DF)







    Ergonomics:

   Adjustable interpupillary distance and diopter settings for comfortable extended use





  Included Components:







   Nikon Eclipse 80i upright microscope stand






   Pair of 10X widefield eyepieces






   Nikon CFI Plan 10X/0.25 Phase Contrast objective






   Nikon CFI Plan 40X/0.65 Phase Contrast objective






   Phase Contrast 0.90 Dry Condenser with 6-position turret (BF, Ph1, Ph2, Ph3, DF, C)






   Mechanical XY stage with manual stage controller






   Illumination system with field diaphragm and aperture diaphragm





  Condition:

 Fully tested and verified. Optics are clean, free of scratches or delamination; stage travel is smooth; phase contrast turret and diaphragms align properly across all positions.


 This Nikon Eclipse 80i system provides a versatile platform for cell biology, microbiology, pathology, and other research applications requiring brightfield, phase contrast, or darkfield imaging with high precision and optical quality.
